Home > Duplex Steel > Duplex Steel Pipe
In the heart of Muscat’s vibrant industrial landscape, Laila Pipes and Tubes has built a reputation for reliability and expertise, particularly as a trusted supplier of Duplex Steel Pipe. We understand that the integrity of your project depends on the quality of its most fundamental components. That’s why we are committed to providing piping solutions that offer superior strength and exceptional corrosion resistance, ensuring longevity and performance even in the most demanding environments, from deep-sea oil fields to complex chemical processing plants.
The exceptional performance of Duplex Steel Pipe comes from its unique composition, a balanced mixture of chromium, nickel, molybdenum, and nitrogen. This specific blend gives the material a two-phase microstructure that combines the best qualities of austenitic and ferritic steels. The result is a pipe with remarkable mechanical properties, including very high tensile strength and excellent resistance to stress corrosion cracking, making it significantly tougher than many conventional stainless steel alternatives.
| Standard | ASTM A790 / ASME SA790 UNS S31803, S32205, S32550, S32750, S32760 |
| Materials | ASTM A815 – UNS S31803 |
| Size | 1/2″NB TO 12 “NB IN |
| Seamless Pipes & Tubes Sizes | 1/2” NB – 8” NB |
| Welded Pipes & Tubes Sizes | 6” NB – 24” NB |
| Thickness | 0.5-45mm |
| Outer Diameter | 6.0-630mm |
| Dimensions | OD(6.0-630)*WT(0.5-45)mm |
| Schedule | SCH20, SCH30, SCH40, STD, SCH80 |
| Type | Welded / Fabricated / Seamless |
| Length | Single Random, Double Random & Cut Length. |
| Ni | Cr | Mo | Mn | Si | C | N | S | P | Fe | |
| MIN | 4.5 | 22.0 | 3.0 | – | – | – | 0.14 | – | – | – |
| MAX | 6.5 | 23.0 | 3.5 | 2.0 | 1.0 | 0.03 | 0.2 | 0.02 | 0.03 | Balance |
| S31803 / S32205 | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Duplex Steel Pipes from Laila Pipes and Tubes ensures high quality and durability, as these pipes offer excellent corrosion resistance and strength. Our commitment to exceptional service and reliable delivery guarantees customer satisfaction across various industrial applications. Our expertise in stainless steel products ensures you receive a top-tier solution tailored to your needs.
Laila Pipes and Tubes, one of the largest suppliers of Duplex Steel Pipes in Muscat, OMAN, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
Yes, we offer custom sizes for Duplex Steel Pipes to meet your specific requirements. Our team at Laila Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@lailapipes.com.
| Nominal pipe size up to 4 = ± 0.79 mm | 5 thru 8 = + 1.58 mm / – 0.79 mm 10 thru 18 = + 2.37 mm / – 0.79 mm | 20 thru 24 = + 3.18 mm / – 0.79 mm | ||
| Wall Thickness All Diameters = – 12.5% + tolerance not specified | Length + 6.40 mm / – 0 mm | Weight Weight = + 10% / – 1.5% |
| Wall | Sizes ( O.D.) |
|---|---|
| .010 | 1/16″ , 1/8″ , 3/16″ |
| .020 | 1/16″ , 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ |
| .012 | 1/8″ |
| .016 | 1/8″ , 3/16″ |
| .028 | 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ , 1/2″ , 3/4″ , 1″ , 1 1/2″ , 2″ |
| .035 | 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ , 7/16″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 2″ , 2 1/4″ |
| .049 | 3/16″ , 1/4″ , 5/16″ , 3/8″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/8″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 2″ , 2 1/4″ |
| .065 | 1/4″ , 5/16″ , 3/8″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 1 3/4″ , 2″ , 2 1/2″ , 3″ |
| .083 | 1/4″ , 3/8″ , 1/2″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 1 7/8″ , 2″ , 2 1/2″ ,3″ |
| .095 | 1/2″ , 5/8″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ |
| .109 | 1/2″ , 3/4″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ |
| .120 | 1/2″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ , 2 1/4″ , 2 1/2″ , 3″ |
| .125 | 3/4″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ , 3″ , 3 1/4″ |
| .134 | 1″ |
| .250 | 3″ |
| .375 | 3 1/2″ |
Duplex Steel Pipes find extensive use in industries that demand superior strength and corrosion resistance. In chemical and petrochemical plants, they safely transport acids, alkalis, and other corrosive substances. In the oil and gas sector, they are utilized in pipelines, heat exchangers, and process equipment that come into contact with seawater and aggressive fluids. Power generation facilities incorporate them in boilers, condensers, and high-temperature systems, while marine industries depend on them for offshore structures and seawater handling applications. Their versatility, durability, and ability to endure extreme conditions make Duplex Steel Pipes an essential choice for various demanding environments.
